Hỗ trợ hệ điều hành

Support for Windows XP/7/8/10

Bộ vi xử lý

Support for Intel® Core™ Core Quad, Core2 Duo, Duo Core, Pentium & Celeron D processors in the LGA775 package

Chipset

Intel® G45 Express Chipset

Đồ họa

Integrated Graphics Processor

Bộ nhớ Ram

2 x 1.5V DDR3 DIMM sockets supporting up to 4 GB of system memory

Ổ đĩa cứng

2 x SATA 3Gb/s connectors (SATA2 0/1) supporting up to 2 SATA 3Gb/s devices

1 X ATA100 connector

Khe cắm mở rộng

1 x PCI Express x16 slot, running at x16. 2 x PCI slots

Lan

Realtek LAN chip (10/100 Mbit)

Âm thanh

Realtek ALC662 codec. High Definition Audio

Giao tiếp

1 x PS/2 mouse port, 1 x PS/2 Keyboard port, 1 x parallel port, 1 x serial port, 1 x D-Sub port, 2 x USB 2.0/1.1 ports, 1 x RJ-45 port, 3 x audio jacks (Line In, Line Out, Mic In)

Hãng sản xuất

Fujisys

Other Supports

1 x 24-pin ATX main power connector, 1 x 4-pin ATX 12V power connector, 1 x ATA connectors, 2 x SATA 3Gb/s connectors, 1 x CPU fan header, 1 x system fan header, 1 x front panel header, 1 x front panel audio header, 2 x USB 2.0/1.1 headers, 1 x Clear CMOS jumper
